Semi Automatic Veterinary Urine Analyzer MDLBW01-VET
- Compact semi-automatic veterinary urine analyzer
- LCD screen with user-friendly software
- Built-in thermal printer for automatic result printing
- Suitable for multiple animal species: Canine, Feline, Equine, Bovine, Porcine, Others
- Offers urine test strip analysis with 10, 11, or 12 parameters
- Immunoassay system with open test strips
- Test speed of 60-120 samples per hour
- Lightweight design weighing ≤3kg
- Ideal for veterinary clinics and laboratories
- SKU
- MDLBW01-VET
- Brand
- MDL
- Manufactured by
- MedicalDeviceLab
- Availability
- In stock
- ✓ Worldwide shipping
Semi Automatic Veterinary Urine Analyzer MDLBW01-VET
Compact, semi-automatic urine analyzer designed for multi-species veterinary diagnostics. Delivers rapid, accurate urinalysis with up to 12 parameter testing, built-in thermal printing, and intuitive LCD interface for canine, feline, equine, bovine, and porcine specimens.
Clinical overview
The MDLBW01-VET is a compact, semi-automatic urine analyzer engineered for rapid multi-species veterinary diagnostics. Suitable for canine, feline, equine, bovine, porcine, and other species, this device combines ease of use with reliable analytical performance. The intuitive LCD interface and built-in thermal printer enable seamless workflow integration in busy veterinary clinics and laboratories.
With test speeds of 60–120 samples per hour and support for 10–12 parameter test strips, the MDLBW01-VET delivers comprehensive urinalysis data including pH, specific gravity, glucose, protein, blood, ketones, bilirubin, urobilinogen, nitrites, leukocytes, ascorbic acid, and microalbumin. The open test strip format provides flexibility and cost efficiency while maintaining diagnostic accuracy across diverse animal species.
Key features & surgeon benefits
Broad Veterinary Applicability
- Supports canine, feline, equine, bovine, and porcine specimens
- Flexible for additional species with appropriate test strips
- Single platform for diverse clinic populations
Rapid Turnaround & Automation
- 60–120 samples per hour processing speed
- Built-in thermal printer for automatic result documentation
- LCD display with user-friendly software interface
Compact & Cost-Effective
- Weighs less than 3 kg for easy bench placement
- Low power consumption at 50 VA
- Open test strip format reduces per-test costs
Comprehensive Parameter Testing
- 10–12 parameter test strips available
- Detection wavelength 525–660 nm for optical accuracy
- Includes pH, glucose, protein, blood, ketones, and more
Technical specifications
| Indications | Urinalysis for canine, feline, equine, bovine, porcine, and other species |
|---|---|
| Test Parameters | 10–12 parameters: pH, specific gravity, glucose, protein, blood, ketones, bilirubin, urobilinogen, nitrites, leukocytes, ascorbic acid, microalbumin |
| Test Speed | 60–120 samples per hour |
| Test Strip Type | Open test strips |
| Detection Wavelength | 525–660 nm |
| Display | 240×64 dot matrix LCD, 37 mm × 130 mm |
| Record Method | Thermal printer and LCD display |
| Power Consumption | 50 VA |
| Net Weight | ≤3 kg |
| Working Environment | 15°C–35°C, humidity <85% |
| Language | English |
| Classification | Class II Medical Device |
| Warranty | 2 Year Manufacturer Warranty |
| After-Sale Service | Online technical support |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Analyzer Unit | Semi-automatic urine analyzer with LCD display and thermal printer | 1 |
| Test Strips | Open format urine test strips (10–12 parameter options) | As ordered |
| Power Cable | Standard laboratory power supply | 1 |
| User Manual | English-language operating and maintenance guide | 1 |
| Thermal Paper | Replacement thermal printer paper roll | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss pricing, bulk orders, and customisation options for the MDLBW01-VET. We offer fast delivery and comprehensive post-purchase technical support.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
Customer reviews
No reviews yet — be the first to share your experience.
