Medical Use 10L Multi-Functional Oxygen Generator for Hospital MDLZY40
- The Medical Use 10L Multi-Functional Oxygen Generator for Hospital MDLZY40 is a reliable and efficient device for hospitals
- It operates at a working voltage of 220V/Hz or 110V/60Hz
- With a rated power of 600W, it has a flow range of 0.5 to 10 L/min
- The oxygen concentration is maintained at ≥90% at all flow rates
- It has a maximum recommended flow rate of 10 L/min with a low noise level of ≤55 dB(A)
- The machine is compact and lightweight, weighing 23kg and measuring 380mm x 330mm x 600mm
- Equipped with safety features like a hypoxic indicator and compressor safety valve release at 250kPa
- SKU
- MDLZY40
- Brand
- MDL
- Manufactured by
- MedicalDeviceLab
- Availability
- In stock
- ✓ Worldwide shipping
Medical Use 10L Multi-Functional Oxygen Generator for Hospital MDLZY40
A compact, reliable 10-litre oxygen concentrator designed for continuous hospital and clinical use. Delivers consistent oxygen concentration ≥90% across all flow rates with integrated safety monitoring and low-noise operation.
Clinical overview
The MDLZY40 is a medical-grade 10-litre oxygen concentrator engineered for continuous operation in hospital, clinic, and home care environments. It reliably extracts and concentrates oxygen from ambient air, delivering consistent therapeutic oxygen at adjustable flow rates from 0.5 to 10 L/min. The device maintains oxygen concentration ≥90% across its entire operating range, meeting international clinical standards for respiratory support and oxygen therapy applications.
Designed with clinician and patient safety as priorities, the MDLZY40 incorporates a hypoxic indicator that alerts users if oxygen concentration falls below 82%, compressor safety valving, and operates at a whisper-quiet ≤55 dB(A) noise level. Its compact footprint (380 × 330 × 600 mm) and lightweight 23 kg construction enable flexible placement in wards, ICUs, and patient rooms, while dual voltage (220V/50Hz or 110V/60Hz) and altitude tolerance up to 2000 metres support global deployment.
Key features & surgeon benefits
Consistent High-Purity Oxygen
- ≥90% oxygen concentration at all flow rates (0.5–10 L/min)
- Rapid stabilisation within 10 minutes of start-up
- Oxygen output pressure 40–60 kPa for reliable delivery
Seamless Clinical Integration
- Continuous flow adjustment without interruption
- Quiet operation (≤55 dB) suitable for patient care areas
- Compact, mobile design for ward and ICU flexibility
Integrated Monitoring & Protection
- Hypoxic indicator alerts if O₂ concentration drops ≤82%
- Compressor safety valve (250 kPa ± 50 kPa) prevents over-pressure
- Outlet temperature control (≤46°C) for patient comfort
Cost-Effective Oxygen Supply
- 600W efficient operation reduces energy consumption
- Lightweight (23 kg) minimises installation and transport costs
- 2-year manufacturer warranty with lifetime technical support
Technical specifications
| Indications | Hospital oxygen therapy, respiratory support, clinical oxygen delivery |
|---|---|
| Flow range | 0.5–10 L/min (continuously adjustable) |
| Oxygen concentration | ≥90% at all flow rates (within 10 min of start-up) |
| Maximum flow rate | 10 L/min (rated) |
| Flow stability at max rate | ≤0.5 L/min variation at 7 kPa back pressure |
| Rated power | 600 watts |
| Working voltage | 220V ± 10% / 50 ± 1 Hz or 110V ± 10% / 60 ± 1 Hz |
| Oxygen output pressure | 40–60 kPa |
| Outlet temperature | ≤46°C |
| Noise level | ≤55 dB(A) |
| Dimensions (L × W × H) | 380 × 330 × 600 mm |
| Net weight | 23 kg |
| Operating altitude | 0–2000 metres (≥90% O₂); 2001–4000 metres (reduced efficiency) |
| Hypoxic indicator | Yellow light at ≤82% ± 3% oxygen concentration |
| Compressor safety valve | 250 kPa ± 50 kPa release pressure |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| MDLZY40 Oxygen Concentrator | 10L/min medical-grade oxygen generator with integrated safety features | 1 |
| Power cable | Dual voltage compatible (220V/110V) | 1 |
| Oxygen outlet tubing | Medical-grade delivery tubing | 1 |
| User manual & safety documentation | Multilingual clinical & operational guidance | 1 |
Get in touch for pricing & availability
Contact our medical device specialists to discuss MDLZY40 procurement, bulk hospital orders, OEM customisation, and regional support. We offer competitive pricing, fast delivery, and comprehensive technical assistance.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
