5L/10L Oxygen Generator Medical Use MDLJY45
- The 5L/10L Oxygen Generator MDLJY45 uses pressure swing absorption (PSA technology) to separate oxygen from nitrogen, producing high-purity oxygen (≥90%).
- It has a flow rate of 10L/min and adjustable oxygen purity of 90%±3%.
- The output pressure ranges from 30-70 kPa for optimal performance.
- This oxygen generator operates quietly at 52dB, ensuring minimal disturbance.
- It is compact in size with dimensions of 335x320x620mm, making it suitable for various settings.
- The product is equipped with a Germany-imported pure copper oil-free compressor for efficient operation.
- Accessories like nasal cannula, adult mask, humidifier bottle, oxygen tube, and nebulizer cup (optional) are included for added convenience.
- SKU
- MDLJY45
- Brand
- MDL
- Manufactured by
- MedicalDeviceLab
- Availability
- In stock
- ✓ Worldwide shipping
5L/10L Oxygen Generator Medical Use MDLJY45
Advanced PSA technology oxygen concentrator delivering 93% ± 3% oxygen purity with adjustable flow rates up to 10L/min. Compact, quiet operation at 52 dB ideal for rehabilitation centers, clinics, and home care environments requiring reliable, continuous oxygen supply.
Clinical overview
The MDLJY45 is a medical-grade oxygen concentrator utilizing advanced Pressure Swing Adsorption (PSA) technology to extract and concentrate oxygen directly from ambient air at normal temperature and pressure. This eliminates the need for oxygen cylinder refills and provides a continuous, reliable oxygen supply for clinical and home care settings. The device produces oxygen at 93% ± 3% purity with adjustable flow rates from 5L to 10L per minute, meeting the therapeutic requirements of patients with chronic respiratory conditions, post-operative recovery, and rehabilitation protocols.
Engineered for clinical environments, the MDLJY45 features a German-imported oil-free compressor and USA-imported HEPA high-efficiency filtration system, ensuring medical-grade air quality and extended device longevity. Its compact footprint (335 × 320 × 620 mm) and low operational noise (52 dB) make it suitable for rehabilitation centers, clinics, and home settings where patient comfort and staff efficiency are priorities. The device is CE and ISO13485 certified, confirming compliance with international medical device standards.
Key features & surgeon benefits
High-Purity Output
- 93% ± 3% oxygen concentration meets clinical standards
- Adjustable 5L–10L/min flow rate for individualized therapy
- Stable 30–70 kPa output pressure for consistent delivery
Quiet, Compact Operation
- 52 dB noise level minimizes patient and staff disruption
- Portable 18.7 kg weight enables flexible placement
- Dual power supply (220V/50Hz or 110V/60Hz) for global deployment
Cost-Effective Therapy
- Eliminates recurring oxygen cylinder refill costs
- Low power consumption at 650VA input
- Extended service life with premium German compressor and HEPA filtration
Complete Therapy Kit
- Nasal cannula and adult mask for flexible patient interface
- Humidifier bottle prevents airway drying
- Oxygen tubing and optional nebulizer cup for aerosol therapy
Technical specifications
| Indications | Rehabilitation centers, oxygen therapy, respiratory support, chronic obstructive pulmonary disease (COPD), post-operative recovery |
|---|---|
| Oxygen Flow | 5L/10L adjustable |
| Oxygen Concentration | 93% ± 3% |
| Output Pressure | 30–70 kPa |
| Power Supply | 220V/50Hz or 110V/60Hz |
| Input Power | 650VA |
| Operation Noise | 52 dB |
| Dimensions | 335 × 320 × 620 mm |
| Packing Size | 445 × 390 × 755 mm |
| Weight (G.W.) | 18.7 kg |
| Compressor | Germany-imported pure copper oil-free compressor |
| Filter | USA-imported HEPA high-efficiency filter |
| Certification | CE/ISO13485 |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Oxygen Concentrator Unit | MDLJY45 5L/10L medical-grade oxygen generator | 1 |
| Nasal Cannula | Standard adult nasal oxygen delivery interface | 1 |
| Adult Mask | Full-face oxygen delivery mask | 1 |
| Humidifier Bottle | Water bottle for oxygen humidification | 1 |
| Oxygen Tubing | Medical-grade oxygen delivery tubing | 1 |
| Nebulizer Cup | Optional aerosol therapy attachment | Optional |
Get in touch for pricing & availability
Contact our medical device specialists to discuss clinical requirements, bulk ordering, and customization options for the MDLJY45 oxygen concentrator. We provide comprehensive technical support and rapid delivery to healthcare facilities worldwide.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
