Veterinary Anesthesia Ventilator MDLBC268
- Veterinary Anesthesia Ventilator MDLBC268
- Tidal volume Range: 20 - 1500ml; Increment: 1 mL
- Respiratory rate Range: 1 ~ 100 bpm
- Inspiratory time Range: 0.1 ~ 10.0 s
- Respiratory ratio Range: 9.9:1 to 1:9.9
- Percentage of inspiratory pause Range: 0 to 50%
- PEEP Range: OFF, 3 ~ 20 cmH2O
- Pressure Support Range: 0 ~ 60 cmH2O
- Monitored parameters for comprehensive respiratory care.
- SKU
- MDLBC268
- Brand
- MDL
- Manufactured by
- MedicalDeviceLab
- Availability
- In stock
- ✓ Worldwide shipping
Veterinary Anesthesia Ventilator MDLBC268
Advanced mechanical ventilation system engineered for small animal and exotic veterinary anesthesia. Delivers precise tidal volume control, flexible respiratory modes, and comprehensive real-time monitoring to ensure optimal patient safety and clinical outcomes during surgical procedures.
Clinical overview
The MDLBC268 is a sophisticated mechanical ventilator designed specifically for veterinary anesthesia applications. It combines precise volume and pressure control with intuitive user interface, enabling clinicians to deliver consistent, safe ventilation across a wide range of animal sizes and physiological conditions. The system supports both controlled and assisted ventilation modes, making it suitable for routine surgical procedures and critical care scenarios.
With adjustable tidal volumes from 20 to 1500 ml and respiratory rates spanning 1 to 100 breaths per minute, the ventilator accommodates everything from small rodents to large companion animals. Real-time monitoring of inspiratory and expiratory tidal volumes, minute ventilation, and airway pressures provides clinicians with immediate feedback on patient status, enabling rapid intervention when needed.
Key features & surgeon benefits
Granular Ventilation Parameters
- Tidal volume adjustable in 1 ml increments (20–1500 ml)
- Inspiratory time control from 0.1 to 10.0 seconds
- Configurable I:E ratios from 9.9:1 to 1:9.9 for tailored ventilation strategies
Intuitive Operation & Monitoring
- User-friendly interface designed for veterinary clinical environments
- Real-time display of tidal volume, minute ventilation, and pressure parameters
- Comprehensive alarm system for peak and mean airway pressure monitoring
Advanced Respiratory Support
- Pressure support (0–60 cmH2O) and pressure control modes for assisted ventilation
- Variable PEEP (3–20 cmH2O) to optimize end-expiratory pressure
- Flow and pressure trigger options for spontaneous breathing support
Optional FiO2 Management
- Adjustable oxygen concentration from 15% to 100%
- Integrated oxygen delivery for enhanced patient oxygenation
- Supports both room air and supplemental oxygen protocols
Technical specifications
| Indications | Mechanical ventilation support in veterinary anesthesia for small animals and exotic species |
|---|---|
| Tidal Volume Range | 20–1500 ml (1 ml increments) |
| Respiratory Rate | 1–100 breaths per minute |
| Inspiratory Time | 0.1–10.0 seconds |
| Respiratory Ratio | 9.9:1 to 1:9.9 |
| Inspiratory Pause | 0–50% |
| PEEP Range | OFF, 3–20 cmH2O |
| Pressure Support | 0–60 cmH2O |
| Pressure Control | 5–60 cmH2O |
| Flow Trigger | 0.5–20 L/min |
| Pressure Trigger | −1 to −20 cmH2O |
| FiO2 (Optional) | 15–100% |
| Peak Airway Pressure Monitoring | 0–100 cmH2O |
| Mean Airway Pressure Monitoring | 0–100 cmH2O |
| Warranty | 2 Year Manufacturer Warranty |
Monitored parameters
| Parameter | Range |
|---|---|
| Inspiratory Tidal Volume | 0–2500 ml |
| Expiratory Tidal Volume | 0–2500 ml |
| Minute Ventilation | 0–60 L/min |
| Spontaneous Minute Ventilation | 0–60 L/min |
| Respiratory Rate | 0–100 bpm |
| Spontaneous Breathing Frequency | 0–100 bpm |
| Respiratory Ratio | 9.9:1 to 1:9.9 |
| Peak Airway Pressure | 0–100 cmH2O |
| Mean Airway Pressure | 0–100 cmH2O |
| PEEP | 0–100 cmH2O |
| Inspiratory Plateau Pressure | 0–100 cmH2O |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Ventilator Unit | Complete MDLBC268 mechanical ventilator with integrated control panel and monitoring display | 1 |
| Patient Circuit | Standard anesthesia breathing circuit with connectors compatible with common anesthesia machines | 1 |
| Power Cable | Medical-grade power supply cable with appropriate regional connectors | 1 |
| User Manual | Comprehensive operating and maintenance documentation | 1 |
