Physical Specification
System Dimension: Height: 245mm Width: 153 mm Depth:41mm
Weight:1.2 kg (2.6 lbs) w.o. transducer
Materials of systems:
Fireproofing and anti‐corrosion ABS, military level
7 “ high resolution TFT color LCD
Monitor:
Resolution: 800*480
Brightness Adjustable
Touchscreen:
Fully resistive touch screen
Physical channels:16
Transducer element: 128
Power:
System operates via AC power(Power supply) & battery
Model:MANGO‐BMV‐12AD‐S
Voltage: 100‐240VAC
AC Adapter:
Battery: (optional)
Frequency: 50/60 Hz
Currency: 2.8A
Output: 15V
Model: LY606090
Lithium‐Ion, 11.1V , 5000mAH
Charge to Full: 6 hours
Max Duration:4.5 hours real-time scan *
vary on the configuration and different working condition, for more details to contact the sales.
Temperature: 0‐40 °C
Display:
|
7 “ high resolution TFT color LCD
|
Mode:
|
B, M, 2B, B/M, 4B
|
Main frequency:
|
2‐12Mhz
|
Measurement:
|
distance, area, OB, backfat, lean rate, etc
|
Battery driving time:
|
about 4.5 hours (Option)
|
Transducer Type:
|
Convex Array,Linear Array,Rectal Linear Array
|
Scanning depth:
|
up to 300mm
|
Transducer element:
|
128
|
Physical channels:
|
16
|
